Application

The tensile strength (1050-1200MPa), the yield strength (900-1100MPa) of the steel strip, and the strength of the lap material are not less than 70% of the material strength.
The insulation layer burning flame retardant grade: GB/T 2408-2008 HB, V0. vertical burning
Insulation layer withstand voltage DC/2700V, 30S, meet leakage current less than 2mA, test standard reference IEC60243-1 (2) -2013, 1000V/DC, 30S, insulation resistance > 500M ohm.
The metal surface treatment: Color zinc plating (neutral salt spray test to meet the 96H, 120H)
Products meet the requirements of RoHS.
Size: customized products
(1) material thickness 0.5-1.2mm
(2) material width 15.0-25.0mm
(3) the product length and width of more than 125.0mm
(4) products of bending R more than 8.0mm

SUS301 technology requirements:

The tensile strength (1100-1300MPa), the yield strength (950-1200MPa) of the steel strip, and the strength of the lap material are not less than 70% of the material strength.
The insulation layer burning flame retardant grade: GB/T 2408-2008 HB, V0. vertical burning
Insulation layer withstand voltage DC/2700V, 30S, meet leakage current less than 2mA, test standard reference IEC60243-1 (2) -2013, 1000V/DC, 30S, insulation resistance > 500M ohm.
The metal surface treatment: stainless steel (neutral salt spray test, meet 120H)
Products meet the requirements of RoHS.
Size: customized products
(1) material thickness 0.5-1.2mm
(2) material width 15.0-25.0mm
(3) the length and width of the product is not less than 125.0mm
(4) stainless steel bending R more than 5.0mm
